OQC 90
The OQC is an OilQuick suspended quick coupler, which is primarily designed for use on material handlers with lifting capacity up to 68 metric tonnes.
Why OQC?
- Hydraulic cylinder with double hose rupture valves. Full system pressure continuously applied to the locking bolts ensures that the attachments are locked securely in place without any play.
- Robust quick coupler made of high-grade steel.
- Wear-free OilQuick tool adapter.
- It only takes one cylinder movement to connect the hydraulic circuits automatically and lock the tools mechanically.
OQC 90
Imperial
Metric
| Rotator | Weight | Max. lift capacity | |
| Coupler | Rotator | ||
| RT1204 | 1358 kg | 873 kg | 54 t |
| RT1504 | 1514 kg | 873 kg | 68 t |
| Max. no. of couplings | Electrical couplings | Max. operating pressure | ||
| 1" | High power 100A | Control power 24 V, 10 Polig | ||
| 4 | Option | Option | 345 bar | |
| Rotator | Weight | Max. lift capacity | |
| Coupler | Rotator | ||
| RT1204 | 2993 Lbs | 1924 Lbs | 54 t |
| RT1504 | 3337 Lbs | 1924 Lbs | 68 t |
| Max. no. of couplings | Electrical couplings | Max. operating pressure | ||
| 1" | High power 100A | Control power 24 V, 10 Polig | ||
| 4 | Option | Option | 5000 Psi | |
OQC 90
Imperial
Metric
| Rotator | RT1204 | RT1504 |
| A | 950 mm | 751 mm |
| B | 752 mm | 1022 mm |
| C | 1100 mm | 750 mm |
| D | 1486 mm | 1214 mm |
| E | 1179 mm | 1516 mm |
| Rotator | RT1204 | RT1504 |
| A | 37.4" | 30" |
| B | 29.6" | 40" |
| C | 43.3" | 30" |
| D | 58.5" | 48" |
| E | 46.4" | 60" |
